Branson 2000X - For a 40 Khz System

Chapter 4: Installation and Setup
Assemble the Acoustic Stack
4-40 011-003-991 EN
4.9.3 For a 40kHz System
10 Repeat Step 7.
11
Securely tighten the adapter sleeve ring nut with the spanner wrenches shipped
with the sleeve assembly.
Step Action
1
Clean the mating surfaces of the converter, booster, and horn. Remove any
foreign material from the threaded holes.
2
Apply a drop of Loctite® 290 (or equivalent) to the studs for the booster and
horn.
3
Install the threaded stud into the top of the booster; torque to 70 in-lbs, 7.91 Nm,
and let cure for 30 minutes.
4
Install the threaded stud into the top of the horn; torque to 70 in-lbs, 7.91 Nm,
and let cure for 30 minutes.
5
Coat each interface surface with a thin film of silicon grease –
but do not apply
silicon grease to a threaded stud or tip.
6 Screw the converter to the booster.
7 Torque to 95 in-lbs, 10.73Nm.
8
Slide the booster/converter assembly into the adapter sleeve. Screw on the
adapter sleeve ring nut and leave loose.
9 Screw the booster onto the horn.
10 Repeat Step 7.
11
Securely tighten the adapter sleeve ring nut with the spanner wrenches shipped
with the sleeve assembly.
