2000X energy Power Supply Appendix A Remote Terminal
Instruction Manual Switching Control Back to the Front Panel
011-003-991 EN A-7
•energy
• frequency change
• set amplitude A
• set amplitude B
When you use Weld Data mode, the weld data and the usual menus share the Remote Terminal screen.
The menus are displayed in the upper portion of the screen, while the weld data appears in the lower portion.
You use the keyboard and the Remote Terminal in the usual way to work with the menus. The weld data is
display-only; you cannot change it or navigate through it.
The Remote Terminal displays a maximum of 16 lines of weld data, each line corresponding to one weld.
The newest weld data appear on the bottom line. Old lines of data move up, and scroll off the top of the
screen if the total number of welds exceeds 16.
To start and stop Weld Data mode, take the following steps:
A.6 Switching Control Back to the Front Panel
To disable the Remote Terminal, take the following steps:
A.7 Turning Off the Remote Terminal
You must turn off the Remote Terminal and Power Supply in the reverse order in which they were turned on.
Step: Action:
1
If you are not currently in Weld Data mode, Press F8 on the Remote Termi-
nal keyboard to start Weld Data mode. Weld data appears on the Remote
Terminal.
2
If you are currently in Weld Data mode, press F8 on the Remote Terminal
keyboard to exit and return the Remote Terminal to its default display.
Step: Action:
1Select System Configuration from the Main Menu.
2 Press Enter. The System Configuration submenu appears.
3
Select Serial Port, and toggle to Off using the F12 key or the Select key
on the Power Supply Front Panel. The Remote Terminal is now disabled.
