Branson 2000X - Page 260

Chapter 7: Maintenance
System Alarm Tables
7-42 011-003-991 EN
Trg > Weld Force The requested trigger force is equal to or greater
than the requested weld force.
Either increase the weld force setting or
decrease the trigger force setting.
2000dt - R Trg > Abs The minus reject trigger limit is greater than or
equal to the absolute distance.
Change the - reject trigger limit and/or the
absolute distance through the Alarm
Information screen or Setup menu.
2000dt - R Trg > +S Abs The minus reject trigger limit is greater than or
equal to the plus suspect absolute distance limit.
Change the - reject trigger limit and/or the
+suspect absolute distance limit through
the Alarm Information screen or Setup
menu.
2000dt - R Trg > +R Abs The minus reject trigger limit is greater than or
equal to the plus reject absolute distance limit.
Change the - reject trigger limit and/or the
+reject absolute distance limit through
the Alarm Information screen or Setup
menu.
Ssequence Empty Preset sequencing is enabled and a start signal
has been received, but there is o sequence
defined.
Define sequence.
2000dt - S Trg > Abs The minus suspect trigger limit is greater than or
equal to the absolute distance.
Change the - suspect trigger limit and/or
the absolute distance through the Alarm
Information screen or Setup menu.
2000dt - S Trg > - S Abs The minus suspect trigger limit value is equal to or
greater than the minus suspect absolute distance
limit.
Change the - suspect trigger limit and/or
the - suspect absolute distance limit
through the Alarm Information screen or
Setup menu.
2000dt +S Trg > +S Abs The plus suspect trigger limit is equal to or greater
than the plus suspect absolute limit.
Change the +suspect trigger limit and/or
the +suspect absolute limit through the
Alarm Information screen or Setup menu.
2000dt Trg S/R Limit Cross The plus reject trigger distance limit is equal to or
less than the minus suspect trigger distance limit.
Change the +reject trigger limit or -
suspect trigger limit through the Alarm
Information screen or Setup menu.
2000dt Trg S/R Limit Cross The plus suspect
trigger distance limit is equal or less than the minus
reject trigger distance limit.
Change the +suspect trigger limit or -
reject trigger limit through the Alarm
Information screen or Setup menu.
2000dt Trg S/R Limit Cross The plus reject trigger distance limit is equal to or
less than the plus suspect trigger distance limit.
Change the +reject trigger limit or
+suspect trigger limit through the Alarm
Information screen or Setup menu.
2000dt Trg S/R Limit Cross The minus reject trigger distance limit is equal to or
greater than the minus suspect trigger distance
limit.
Change the - reject trigger limit or -
suspect trigger limit through the Alarm
Information screen or Setup menu.
Table 7.8 Setup Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Alarm Condition/Cause Corrective Action
