Branson 2000X - Page 115

2000X energy Power Supply Chapter 6: Operation
Instruction Manual Setting Primary Parameters
011-003-991 EN 6-23
2000X Power Supply Main Menu: Weld Setup (Peak Power Mode)
WELD SETUP
Pg1of20
Weld Mode> Peak
Power
Peak Power(%)=
100.0
Hold time(s)= 30.000
Ext U/S Delay =
Amplitude> STEP
Amplitude(%)= 50
Pretrigger> Off
Afterburst> Off
Energy Brake =
Digital UPS >
Post Weld Seek = Off
Frequency Offset> Off
AMP STEP Pge1of5
Amplitude A(%)= 100
Amplitude B(%)= 100
Step @ T(s)= Off
Step @ E(J)= Off
MAIN MENU
Pge1of6
Run Screen
Weld Setup
Save/Recall Presets
Print Menu
Diagnostics
System Information
System Configuration
FREQ OFFSET
Pg1of1
WELD MODE
Pg1of4
Time= Off
Energy= Off
REJ LIMITS Pg1of13
Reset Required= On
+R Time(s)= 30.000
-R Time(s)= 30.000
+R Energy(J)= 60000
SUSP LIMITS Pg1of13
Reset Required= On
+S Time(s)= 30.000
-S Time(s)= 30.000
+S Energy(J)= 60000
WRITE IN FIELD
Pg1of1
Text1 ABC
