Setting Weld Energy
You can select the amount of ultrasonic energy (in Joules) that will be transmitted to your
parts.
Take this action… To get this result…
Press the Select key that corresponds to
Weld Energy(J).
Use the numeric keypad to enter the Weld
Energy (in Joules) that you want to use, or
press the same Select key again to toggle
between the minimum value (1.0 joule) and
the maximum value (66000 joules) for
Weld Energy.
Press Enter on the numeric keypad to save
the new value, or press Go Back/Esc to
make no change to the value.
WELD SETUP Pg1of20
Weld Mode> Energy
Weld Energy(J)=30000
Hold Time (s)=30.000
Select
Select
Select
WELD SETUP Pg1of20
Weld Mode> Energy
Weld Energy(J)= 150
Hold Time(s)= 30.000
Select
Select
Select
WELD SETUP Pg1of20
Weld Mode> Energy
Weld Energy(J)= 150
Hold Time(s) = 30.000
Enter
