Chapter 7: Maintenance
System Alarm Tables
7-46 011-003-991 EN
The following table details the Note alarms you can encounter on the 2000X Power Supply. The message
on the display panel of the Power Supply is shown in the first column; the detailed message you can print
is in the second column. The third and fourth columns indicate the condition that led to the alarm and the
corrective action you should take.
Table 7.10 Note Alarms
Model Display Message Printer Message
Alarm Condition/
Cause
Corrective Action
2000dt Absolute Cutoff Absolute Distance
Cutoff
The absolute cutoff
distance that you requested
has been reached.
Manually inspect the part. If,
with acceptable parts, you
repeatedly get this alarm,
reset your Absolute cutoff.
2000dt Act Clr Not Reached Actuator Clear
Distance Not
Reached
The actual absolute
distance reached during the
weld cycle did not reach the
Actuator clear distance that
you set.
Using Horn Down to obtain
size and distance readings,
reset your Actuator Clear
Distance to an obtainable
value.
2000dt Act Recal
Suggested
For optimum
performance re
calibrate your
Actuator
A preset has been loaded
and calibration should be
run
Calibrate Actuator through
Note menu, or calibrate
from the Main Menu.
Act Recal
Suggested
Act Recal
Suggested
A preset has been loaded
and calibration should be
run.
Additional information will
not be available if the
carriage is not at upper limit,
the actuator Novram has
failed or the palm buttons
are still pressed. This note
will be disabled when the
preset has been recalled via
external preset selection,
through the host or
sequencing.
2000dt Collapse Cutoff Collapse Cutoff The collapse cutoff
distance you requested has
been reached.
Manually inspect the part. If
you repeatedly get this
alarm with acceptable parts,
reset your collapse cutoff.
2000a
2000dt
2000e
Max Energy
Reached
Energy
Compensation
Maximum Energy
Reached
The maximum energy
compensation value has
been reached.
None. This is only a notice
that an adaptive control
feature that you
programmed is in use.
2000a
2000dt
2000e
2000t
Print Buffer [No message sent to
printer.]
The printer buffer is at 80%
of capacity. Cycle rate will
slow to allow data to print.
Slow the cycle rate or
request less printing.
Sonics Disabled Ultrasonics Disabled
by user input
A complete weld cycle has
been run but the ultrasonics
were disabled by a user
defined input.
Remove 24V from Sonics
Disable input; undefine
Sonics Disable input pin.
