Chapter 4: Installation and Setup
Start Switch Connection (Automation)
4-28 011-003-991 EN
Table 4.6 User I/O Cable Pin Assignments, Alphabetical Order
Pin Signal Name Signal Type Direction Signal Range Definition Colors
7 ACT_CLEAR 24V Logic 0 True Output 0/24V, 100mA Actuator clear signal Red/Wht
24 AMPLITUDE_OUT Analog Output 0V to 10V Amplitude signal from PS Red/Blk/Grn
2 CYCLE_ABORT 24V Logic 1 True Input 0/24V, 100mA Red/Blk
3 EXT_RESET 24V Logic 1 True Input 0/24V, 100mA System Reset Grn/Blk
18 EXT_SEEK+ 24V Logic 1 True Input 0/24V, 100mA Red/Blk/Wht
38 FREQ_OUT Analog Output -10V to +10V Frequency Signal from PS Blk/Wht/Blu
6 G_ALARM 24V Logic 0 True Output 0/24V, 100mA Blk/Wht
14 GEN_ALARM_RELAY_1 Relay Contact Output 40V, 0.25A Contact Closure Red/Grn
29 GEN_ALARM_RELAY_2 Relay Contact Output 40V, 0.25A Contact Closure Wht/Red/Orn
1 J3_1_INPUT 24V Logic 1 True Input 0/24V, 100mA User definable inputs. Refer to
Table 4.7 to view available
selections.
Wht/Blk
17 J3_17_INPUT 24V Logic 1 True Input 0/24V, 100mA Wht/Blk/Red
19 J3_19_INPUT 24V Logic 1 True Input 0/24V, 100mA Grn/Blk/Wht
31 J3_31_INPUT 24V Logic 1 True Input 0/24V, 100mA Wht/Red/Blu
32 J3_32_INPUT 24V Logic 1 True Input 0/24V, 100mA Blk/Grn/Wht
33 J3_33_INPUT 24V Logic 1 True Input 0/24V, 100mA Wht/Blk/Grn
8 J3_8_OUTPUT 24V Logic 0 True Output 0/24V, 100mA User definable outputs. Refer to
Table 4.7 to view available
selections.
Grn/Wht
22 J3_22_OUTPUT 24V Logic 0 True Output 0/24V, 100mA Blk/Red/Grn
36 J3_36_OUTPUT 24V Logic 0 True Output 0/24V, 100mA Orn/Red Grn
9 MEM Analog Output -10V to +10V Memory Signal from PS Blu/Wht
11 MEM_CLEAR Open Collector Output 24V, 25mA max Memory Clear signal send to PS Wht/Red
40 MEMORY_STORE Open Collector Output 24V, 25mA max Memory store from PS Red/Wht/Blu
34 PB_RELEASE 24V Logic 0 True Output 0/24V, 100mA Red/Wht/Grn
37 PWR Analog Output 0V to 10V Power Signal from PS Blu/Red/Grn
21 READY 24V Logic 0 True Output 0/24V, 100mA Blu/Blk/Wht
5 REJECT 24V Logic 0 True Output 0/24V, 100mA Blu/Blk
43 READY_ RELAY_1 Relay Contact Output 40V, 0.25A Contact Closure Blu/Orn/Red
15 READY_RELAY_2 Relay Contact Output 40V, 0.25A Contact Closure Orn/Grn
26 RUN Open Collector Output 24V, 25mA max Run signal send to PS Orn/Blk/Grn
39 SEEK Open Collector Output 24V, 25mA max Seek Signal send to PS Wht/Blk/Blu
4 SOL_VALVE_SRC 24V Output 0/24V, 125mA SV1 Source Orn/Blk
16 SOL_VALVE_RTN 24V Return Input 0V SV1 Return Blk/Wht/Red
20 SUSPECT_PART 24V Logic 0 True Output 0/24V, 100mA Orn/Blk/Wht
10 USER_AMP_IN Analog Input -10V to +10V User Amplitude control signal Blk/Red
25 USER_FREQ_OFFSET Analog Input -10V to +10V User Freq. offset control signal Grn/Blk/Orn
35 WELD_ON 24V Logic 0 True Output 0/24V, 100mA Start of sonics and trigger Grn/Wht/Blu
30 WELD_ON_RELAY_1 Relay Contact Output 40V, 0.25A Contact Closure Orn/Wht/Blu
44 WELD_ON_RELAY_2 Relay Contact Output 40V, 0.25A Contact Closure Blk/Orn/Red
note: User can change 24V Logic 0 True to 1 Continued next page
