■ Paper jam at the 2-sided tray
<User Check>
- Turn back the paper loaded in each paper tray or change the orientation of the paper by
180
° .
- Check if the thickness of the paper is 60 to 105 g/m
2
.
- Fan the stack of paper well and reinsert the papers into each paper tray.
Step Cause Remedy
1 Foreign object in the 2-sided
paper feed system
Remove the foreign object.
2 Coming off of eject actuator Re-assemble the eject actuator.
3 Back cover failure Replace the back cover.
4 Paper eject sensor failure Replace the paper eject ASSY.
5 Paper feed PCB failure Replace the paper feed PCB ASSY.
6 Main PCB failure Replace the main PCB ASSY.
