5-12
Confidential
Menu Sub Menu
Operation
Key LCD
Key
LCD
3
BlackWipe
1
HOME POSITION Moves to the home position.
2
INK DRAIN POS Moves to the ink drain position.
3
GLASS WIPE
POS
Moves to the glass wipe ready
position.
4
NOZZLE WIPE
POS
Moves to the nozzle wipe ready
position.
5
ON(CW)
Turns ON the ink wiper motor forcibly
(In the direction of the ready position)
and automatically stops in 2 sec.
6
ON(CCW)
Turns ON the ink wiper motor forcibly
(In the direction of the home position)
and automatically stops in 2 sec.
4
PrecoatWipe
1
HOME POSITION Moves to the home position.
2
INK DRAIN POS Moves to the ink drain position.
3
GLASS WIPE
POS
Moves to the glass wipe ready
position.
4
NOZZLE WIPE
POS
Moves to the nozzle wipe ready
position.
5
ON(CW) Turns ON the pre-coat wiper motor
forcibly
(In the direction of the ready position)
and automatically stops in 2 sec.
6
ON(CCW) Turns ON the pre-coat wiper motor
forcibly
(In the direction of the home position)
and automatically stops in 2 sec.
5
Cap
1
CAP POSITION Moves to the cap position.
2
UNCAP
POSITION
Moves to the uncap position.
3
ON Turns ON the cap motor forcibly
6
SubtankValve
1
OPEN Opens the sub tank valve.
2
CLOSE Closes the sub tank valve.
7
SubtankPump
1
ON(BK) Turns ON the sub tank pump
(Ink)
2
ON(PRE) Turns ON the sub tank pump
(Precoat)
8
WastePump
1
ON Turns ON the waste ink pump
9
Ventilation
Valve
1
OPEN Opens the air vent valve.
2
CLOSE Closes the air vent valve.
*
Optimizer
Supply
1
SUPPLY
OPTIMIZER
Turns ON the motor until optimizer
becomes full.
2
ON Turns ON the motor forcibly
and automatically stops in 2 sec.
To Next Page
