Brother HL-S7000DN - Page 414

5-26
Confidential
 Paper feed unit
Fig. 5-11
 Frame
Fig. 5-12
Top cover sensor
Paper feed jam sensor
MP paper empty sensor
Tray1 plate sensor/Tray1 paper empty sensor
Registration sensor
Tray1 paper size sensor
Main PCB leak sensor
Tray1 ID switch
2-sided size sensor/2-sided jam sensor
