2-16
Confidential
3601 Paper eject switching sensor
detected that either optional
output tray is selected or paper
eject switching is not set to
optional output tray.
2-63
3700 ---
3701 Serial communication error
occurred between RIP CPU
when PC printing, internal
printing, and storage printing
etc. was performed.
2-63
3702 Serial communication error
occurred between RIP CPU
when RIP CPU is activated.
2-63
3703 Serial communication between
RIP CPU occurred after watch
dog timer time out occurred.
2-63
3801 Error occurred in the external
temperature sensor.
2-64
3802 Error occurred in the external
humidity sensor.
2-64
3900 ---
3A00 Communication error occurred
between the engine and control
on the main PCB.
2-64
3B00 Error occurred when main PCB
ASSY is accessing to DRAM.
2-64
3C00 ---
3D00 ---
3E00 ---
3F00 ---
4000 ---
4200 ---
4300 ---
4400 ---
Error
Codes
Problem
Refer
to:
4500 ---
4600 ---
4700 ---
4800 ---
4900 ---
4A00 ---
4B00 ---
4C00 ---
4D00 ---
4E00 ---
4F00 ---
5000 ---
5001 The use number of sheets for
paper feeding kit MP reached
the end of life. (Printing does
not stop.)
2-65
5002 The use number of sheets for
paper feeding kit 1 reached the
end of life. (Printing does not
stop.)
2-65
5003 The use number of sheets for
paper feeding kit 2 reached the
end of life. (Printing does not
stop.)
2-65
5004 The use number of sheets for
paper feeding kit 3 reached the
end of life. (Printing does not
stop.)
2-65
5005 The use number of sheets for
paper feeding kit 4 reached the
end of life. (Printing does not
stop.)
2-65
5100 Waste dot count detected that
waste ink tank almost reached
the time for replacement.
2-66
5200 Waste ink full sensor detected
that waste ink tank reached
time for replacement.
2-66
Error
Codes
Problem
Refer
to:
To Next Page
