Cisco ASR 1002-X Hardware Installation Guide

Radio Frequency Interference 127
Lightning and AC Power Fault Interference 127
Rack-Mounting Guidelines 127
Precautions for Rack-Mounting 127
General Rack Selection Guidelines 128
Guidelines for 23 in. (Telco) Racks 128
Equipment Rack Guidelines 129
Locating for Safety 129
Locating for Easy Maintenance 129
Locating for Proper Airflow 130
Site Planning Checklist 130
Preventing Electrostatic Discharge Damage 130
Electrical Safety 131
Receiving the Cisco ASR 1000 Series Router 132
Chassis-Lifting Guidelines 133
Tools and Equipment 134
Unpacking and Verifying Shipping Contents 134
Checking the Shipping Container Contents 135
Cisco ASR 1000 Series Router Installation Checklist 136
CHAPTER 6 Cisco ASR 1006 Router Overview and Installation 139
Cisco ASR 1006 Router Description 139
Front View 140
Rear View 141
Cisco ASR 1006 Router Slot Numbering 142
Installation Methods 143
General Rack Installation Guidelines 143
Guidelines for an Equipment Shelf or Tabletop Installation 145
Equipment Shelf or Tabletop Installation 146
Rack-Mounting the Cisco ASR 1006 Router 148
Verifying Rack Dimensions 148
Attaching the Chassis Rack-Mount Brackets 149
Chassis Front Rack-Mount Brackets 149
Chassis Rear Rack-Mount Brackets 151
Installing the Cisco ASR 1006 Router in a Rack 153
Cisco ASR 1000 Series Router Hardware Installation Guide
vii
Contents

Cisco ASR 1002-X Specifications

General

Form Factor	Rack-mountable
Rack Units	2RU
Integrated Services	Yes
Maximum Memory	16 GB
Built-in Gigabit Ethernet Ports	6
Input Voltage	100-240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
Redundancy	Power supply redundancy
Network Interface Modules	Up to 4 SPA/SIP slots
Embedded Services Processor (ESP)	ESP-20
Maximum Packet per Second (PPS)	15 Mpps
Height	3.5 inches
Fixed Ports	6 GE ports
Memory	4 GB (default), 16 GB (maximum)
Power Supply	Dual power supplies (AC or DC)
Dimensions (H x W x D)	3.5 x 17.5 x 19.0 in (8.9 x 44.5 x 48.3 cm)
