Chapter 5 Provisioning Additional Subsystems
Provisioning the HTTP Subsystem
5-10
Cisco Customer Response Solutions Administration Guide, Release 4.1(1)
Step 4 Click Add.
The HTTP Trigger Configuration web page closes, and the trigger information
appears on the HTTP Trigger Configuration summary web page.
You are now ready to provision any additional subsystems your CRS applications
require or to begin configuring CRS applications. See Configuring Cisco
Applications, page 6-1.
Changing Port Numbers
You can set the TCP/IP port number the CRS Engine uses for the internal HTTP
server when you install the HTTP subsystem. The default port used during
installation is port 8080.
After the HTTP subsystem is installed, you can change the port in the Tomcat
server.MIVR.xml file.
To change the TCP/IP port number, complete the following steps.
Note You need to follow these steps on all the CRS Engine-enabled nodes in the cluster.
Maximum Number of
sessions
The maximum amount of simultaneous sessions (instances) that the
application can handle.
Note The limit for the maximum number of simultaneous remote
monitoring sessions is 16, but the actual number depends on your
system’s CPU and memory resources. Entering a number that is too
high can result in unacceptable system performance.
Idle Timeout (in ms) The number of milliseconds the system should wait before rejecting the
HTTP request for this trigger,
Enabled Radio buttons. Valid options:
Yes - enable the trigger,
No - disable the trigger.
Field Name Description
