DescriptionSetting
Displays pickup groups that are monitored by the
current group.
Each group can monitor only up to 10
pickup groups including itself. A message
displays the number of pickup groups that
are monitoring the current group. Click the
Show All link to view the details of these
monitoring groups. If there are no such
groups, this message does not appear.
Note
Tip: Click the > or < button to move the selected
group from the Available list to the Selected list or
vice versa.
Tip: The priority in which the pickup is handled can
be determined by ordering the groups accordingly in
the Selected monitored groups list. The higher a
group is in the Selected list, the higher the priority
it has for pickup and vice versa.
Selected
Click to save the updated settings.Save
Click to discard unsaved changes.Reset
Administration Guide for Cisco Business Edition 3000, Release 8.6(4)
168 OL-27022-01

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
