Cisco IE-3000-8TC Administration Guide

DescriptionSetting
This field specifies the maximum waiting time before retransmitting
the OPTIONS request.
Valid values range from 100 to 1000 milliseconds. The default value
specifies 500 milliseconds.
Retry Timer (ms)
This field specifies the number of times that Cisco Business Edition
3000 resends the OPTIONS request to the remote peer. After the
configured retry attempts are used, the destination is considered to
have failed. To obtain faster failure detection, keep the retry count
low.
Valid values range from 1 to 10. The default value specifies 6.
Retry Count
Connection Type: FXO
Table 69: Connection settings for SPA8800 Connection Type
DescriptionSettings
Basic Parameters
Also referred to as Line Number, this is the corresponding FXO
analog port on the SPA8800. Ports assigned to other PSTN
connections are not available for selection.
Port
This field describes the FXO connection.Description
This field specifies the number associated to the PSTN connection.
By default, this number will route to the auto-attendant unless
additional configurations to make the number routable to a callable
endpoint are performed.
Direct Inward Dial (DID) Number
Administration Guide for Cisco Business Edition 3000, Release 8.6(4)
294 OL-27022-01
Connection Settings

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
