CDM-625A Advanced Satellite Modem MN-CDM625A
CDM-625A ODU (Transceiver, BUC, LNB) Operation Revision 4
10–55
10.5.1.2.1 Home > Outdoor Unit (ODU) > CSAT-5060 Submenu
Open the nested CSAT-5060 submenu from the Outdoor Unit (ODU) submenu. This submenu
contains the following options:
Hot
Key
Dialog Window Option Entry Sect.
A Select Use the ↑↓ arrow keys to select Csat1 or Csat2 N/A
B Up Converter Settings (1/2)
Configure an Up Converter 10.5.1.2.1.1
C Up Converter Settings (2/2)
D Down Converter Settings (1/2)
Configure a Down Converter 10.5.1.2.1.2
E
Down Converter Settings (2/2)
F
Unit Settings (1/2)
Configure an ODU 10.5.1.2.1.3
G
Unit Settings (2/2)
H
LNA Settings
Configure a Low Noise Amplifier
10.5.1.2.1.4
I
Status
Review ODU Status Information
10.5.1.2.1.5
J
Logs
Review and manage Event Logs
10.5.1.2.1.6
K
Redundancy Configure ODUs for 1:N Redundancy
10.5.1.2.1.7
L Utilities
Set device time and date, review the unit’s
firmware version and serial number
10.5.1.2.1.8
Press a hot key to open a dialog window or configuration page. See the specified chapter section
for further configuration options. Otherwise, press [ESC] to return to the ODU submenu.
