xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
100
dst_port_mask <hex 0x0-0xffff>} | protocol_id_mask <hex 0x0-0xff> {user_define_mask
<hex 0x0-0xffffffff>}]}(1) | packet_content_mask {offset_chunk_1 <value 0-31> <hex 0x0-
0xffffffff> | offset_chunk_2 <value 0-31> <hex 0x0-0xffffffff> | offset_chunk_3 <value 0-31>
<hex 0x0-0xffffffff> | offset_chunk_4 <value 0-31> <hex 0x0-0xffffffff>}(1) | ipv6 {class |
flowlabel | source_ipv6_mask <ipv6mask> | destination_ipv6_mask <ipv6mask> | [tcp
{src_port_mask <hex 0x0-0xffff> | dst_port_mask <hex 0x0-0xffff>} | udp {src_port_mask
<hex 0x0-0xffff> | dst_port_mask <hex 0x0-0xffff>} | icmp {type | code}]}(1)]
Parameters
<value 1-6> - Enter the profile ID between 1 and 6. The lower the profile ID, the higher the
priority.
profile_name - Specifies a profile name.
<name 1-32> - The maximum length is 32 characters.
ethernet - Specifies an Ethernet access control list rule.
vlan - Specifies a VLAN mask. Only the last 12 bits of the mask will be considered.
<hex 0x0-0x0fff> - (Optional) Specify a VLAN mask.
source_mac - Specifies the source MAC mask.
<macmask 000000000000-ffffffffffff> - Enter the source MAC mask.
destination_mac - Specifies the destination MAC mask.
<macmask 000000000000-ffffffffffff> - Enter the destination MAC mask.
802.1p - Speciy the 802.1p priority tag mask.
ethernet_type - Specifies the Ethernet type.
ip - Specifies an IP access control list rule.
vlan - Specifies a VLAN mask. Only the last 12 bits of the mask will be considered.
<hex 0x0-0x0fff> - (Optional) Specify a VLAN mask.
source_ip_mask - Specifies an IP source submask.
<netmask> - Enter an IP source submask.
destination_ip_mask - Specifies an IP destination submask.
<netmask> - Enter an IP destination submask.
dscp - Specifies the DSCP mask.
icmp - Specifies that the rule applies to ICMP traffic.
type - (Optional) Specify the ICMP packet type.
code - (Optional) Specify the ICMP code.
igmp - Specifies that the rule applies to IGMP traffic.
type - (Optional) Specify the IGMP packet type.
tcp - Specifies that the rule applies to TCP traffic.
src_port_mask - (Optional) Specify the TCP source port mask.
<hex 0x0-0xffff> - Enter the TCP source port mask.
dst_port_mask - (Optional) Specify the TCP destination port mask.
<hex 0x0-0xffff> - Enter the TCP destination port mask.
flag_mask - (Optional) Specify the TCP flag field mask.
all – Specify to check all paramenters below.
urg - (Optional) Specify Urgent Pointer field significant.
ack - (Optional) Specify Acknowledgment field significant.
psh - (Optional) Specify Push Function.
rst - (Optional) Specify to reset the connection.
syn - (Optional) Specify to synchronize sequence numbers.
fin - (Optional) No more data from sender.
udp - Specifies that the rule applies to UDP traffic.
src_port_mask - (Optional) Specify the TCP source port mask.
<hex 0x0-0xffff> - Enter the TCP source port mask.
dst_port_mask - (Optional) Specify the TCP destination port mask.
<hex 0x0-0xffff> - Enter the TCP destination port mask.
protocol_id_mask - Specifies that the rule applies to the IP protocol ID traffic.
<hex 0x0-0xff> - Enter that the rule applies to the IP protocol ID traffic.
user_define_mask - (Optional) Specify the L4 part mask.
<hex 0x0-0xffffffff> - Enter the L4 part mask.
