xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
974
Format
config port dot1v ports [<portlist> | all] [add protocol_group [group_id <int 1-16> |
group_name <name 32>] [vlan <vlan_name 32> | vlanid <id>] {priority <value 0-7>} | delete
protocol_group [group_id <int 1-16> | all]]
Parameters
<portlist> - Enter a range of ports to apply this command.
all - Specifies all ports.
add protocol_group - Specifies to add a protocol group.
group_id - Specifies the group ID of the protocol group.
<int 1-16>- Specifies the group ID of the protocol group.
group_name - Specifies the name of the protocol group.
<name 32> - Enter the name of the protocol group. The maximum length is 32 characters.
vlan - Specifies the VLAN that is to be associated with this protocol group on this port.
<vlan_name 32> - Enter the VLAN that is to be associated with this protocol group on this
port. The maximum length is 32 characters.
vlanid - Specifies the VLAN ID.
<id> - Enter the VLAN ID.
priority - Specifies the priority to be associated with the packet which has been classified to the
specified VLAN by the protocol.
<value 0-7> - Enter a value between 0 and 7.
delete protocol_group - Specifies to delete a protocol group.
group_id – Specify the group ID to be deleted.
<int 1-16> - Enter the group ID.
all – Specify all groups.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the group ID 4 on port 3 to be associated with VLAN 2:
DGS-3620-28SC:admin# config port dot1v ports 3 add protocol_group group_id 4
vlan VLAN2
Command: config port dot1v ports 3 add protocol_group group_id 4 vlan VLAN2
Success.
DGS-3620-28SC:admin#
84-6 show port dot1v
Description
This command is used to display the VLAN to be associated with untagged packets ingressed
from a port based on the protocol group.
Format
show port dot1v {ports <portlist>}
