xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
658
Chapter 53
LACP Configuration
Commands
config lacp_port <portlist> {mode [active | passive] | lacp_timeout [short | long]}
show lacp_port {<portlist>}
53-1 config lacp_port
Description
This command is used to configure per-port LACP mode.
Format
config lac
p_port <por
tlist> {mode [ac
tive | passi
ve] |
lacp_timeout [short | long]}
Parameters
<portlist> - Enter a range of ports to be configured.
mode - (Optional) Specify the port mode.
active - Specifies the mode as active.
passive - Specifies the mode as passive.
lacp_timeout - Specifies the LACP timeout mode.
short - Specifies that there will be 3 seconds before LACP invalidating received LACPDU
information and there will be 1 second between LACP PDU periodic transmissions when
using Short Timeouts.
long - Specifies that there will be 90 seconds before LACP invalidating received LACPDU
information and there will be 30 seconds between LACP PDU periodic transmissions when
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure port LACP mode for ports 1 to 3:
DGS-3620-28SC:admin#config lacp_port 1-3 mode active
Command: config lacp_port 1-3 mode active
Success.
