xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
104
ip - Specifies an IP access control list rule.
vlan - Specifies the VLAN name.
<vlan_name 32> -Specify the VLAN name. The maximum length is 32 characters.
vlanid - Specifies the VLAN ID.
<vlanid 1-4094> - Enter the VLAN ID between 1 and 4094.
mask - (Optional)Specify the mask.
<hex 0x0-0x0fff> - Enter the mask.
source_ip - Specifies an IP source address.
<ipaddr> - Enter an IP source address.
mask - (Optional) Specify the mask.
<netmask> - Enter the mask.
destination_ip - Specifies an IP destination address.
<ipaddr> - Enter an IP destination address.
mask - (Optional) Specify the mask.
<netmask> - Enter the mask.
dscp - Specifies the value of DSCP.
<value 0-63> - Enter the value of DSCP. The DSCP value ranges from 0 to 63.
icmp - Specifies the ICMP.
type - (Optional) Specify that the rule will apply to the ICMP Type traffic value.
<value 0-255> - Enter the value between 0 and 255.
code - (Optional) Specify that the rule will apply to the ICMP Code traffic value.
<value 0-255> - Enter the value between 0 and 255.
igmp - Specifies the IGMP.
type - (Optional) Specify that the rule will apply to the IGMP Type traffic value.
<value 0-255> - Enter the value between 0 and 255.
tcp - Specifies TCP.
src_port - (Optional) Specify that the rule will apply to a range of TCP source ports.
<value 0-65535> - Enter the value between 0 and 65535.
mask - (Optional) Specify the mask.
<hex 0x0-0xffff> - Enter the mask.
dst_port - (Optional) Specify that the rule will apply to a range of TCP destination ports.
<value 0-65535> - Enter the value between 0 and 65535.
mask - (Optional) Specify the mask.
<hex 0x0-0xffff> - Enter the mask.
flag - Specifies the TCP flag field value.
all – Specify to check all paramenters below.
urg - (Optional) Specify Urgent Pointer field significant.
ack - (Optional) Specify Acknowledgment field significant.
psh - (Optional) Specify Push Function.
rst - (Optional) Specify to reset the connection.
syn - (Optional) Specify to synchronize sequence numbers.
fin - (Optional) No more data from sender.
udp - Specifies UDP.
src_port - (Optional) Specify the UDP source port range.
<value 0-65535> - Enter the value between 0 and 65535.
mask - (Optional) Specify the mask.
<hex 0x0-0xffff> - Enter the mask.
dst_port - (Optional) Specify the UDP destination port range.
<value 0-65535> - Enter the value between 0 and 65535.
mask - (Optional) Specify the mask.
<hex 0x0-0xffff> - Enter the mask.
protocol_id - Specifies that the rule will apply to the value of IP protocol ID traffic.
<value 0-255> - Enter the value between 0 and 255.
user_define - (Optional) Specify that the rule will apply to the IP protocol ID and that the mask
options behind the IP header, which has a length of 4 bytes.
<hex 0x0-0xffffffff> - Enter that the rule will apply to the IP protocol ID and that the mask
options behind the IP header, which has a length of 4 bytes.
mask - (Optional) Specify the mask.
<hex 0x0-0xffffffff> - Enter the mask.
packet_content - Specifies the packet content for the user defined mask.
