xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
1106
vlan - (Optional) Specify the VLAN associated with the MAC address.
<vlan_name 32> - Enter the VLAN name. The maximum length is 32 characters.
vlanid - (Optional) Specify the VLAN ID associated with the MAC address.
<vlanid 1-4094> - Enter the VLAN ID between 1 and 4094.
Restrictions
None.
Example
In the following example, MAC address “00-80-c2-33-c3-45” is assigned to VLAN 300 by manual
configuration. It is assigned to VLAN 400 by MAC-AC. Since MAC AC has higher priority than
manual configuration, the manually configured entry will become inactive. To display the MAC-
based VLAN entries:
DGS-3620-28SC:admin#show mac_based_vlan
MAC Address VLAN ID Status Type
------------------ ------------ ----------- --------
00-80-e0-14-a7-57 200 Active Static
00-80-c2-33-c3-45 300 Inactive Static
00-80-c2-33-c3-45 400 Active MAC_based Access Control
00-a2-44-17-32-98 400 Active WAC
Total Entries : 4
