xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
114
ip - Specifies an IP CPU access control list rule.
vlan - Specifies a VLAN mask.
source_ip_mask - Specifies an IP source submask.
<netmask> - Enter an IP source submask.
destination_ip_mask - Specifies an IP destination submask.
<netmask> - Enter an IP destination submask.
dscp - Specifies the DSCP mask.
icmp - Specifies that the rule applies to ICMP traffic.
type - (Optional) Specify the ICMP packet type.
code - (Optional) Specify the ICMP code.
igmp - Specifies that the rule applies to IGMP traffic.
type - (Optional) Specify the IGMP packet type.
tcp - Specifies that the rule applies to TCP traffic.
src_port_mask - (Optional) Specify the TCP source port mask.
<hex 0x0-0xffff> - Enter the TCP source port mask.
dst_port_mask - (Optional) Specify the TCP destination port mask.
<hex 0x0-0xffff> - Enter the TCP destination port mask.
flag_mask - (Optional) Specify the TCP flag field mask.
all – Specify to check all paramenters below.
urg - (Optional) Specify Urgent Pointer field significant.
ack - (Optional) Specify Acknowledgment field significant.
psh - (Optional) Specify Push Function.
rst - (Optional) Specify to reset the connection.
syn - (Optional) Specify to synchronize sequence numbers.
fin - (Optional) No more data from sender.
udp - Specifies that the rule applies to UDP traffic.
src_port_mask - (Optional) Specify the UDP source port mask.
<hex 0x0-0xffff> - Enter the UDP source port mask.
dst_port_mask - (Optional) Specify the UDP destination port mask.
<hex 0x0-0xffff> - Enter the UDP destination port mask.
protocol_id_mask - Specifies that the rule applies to the IP protocol ID traffic.
<hex 0x0-0xff> - Enter that the rule applies to the IP protocol ID traffic.
user_define_mask - (Optional) Specify the L4 part mask
<hex 0x0-0xffffffff> - Enter the L4 part mask
packet_content_mask - Specifies the packet content mask.
offset_0-15 - Specifies the mask for packet bytes 0-15.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 0-3.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 4-7.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 8-11.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 12-15.
offset_16-31 - Specifies the mask for packet bytes 16-31.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 16-19.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 20-23.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 24-27.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 28-31.
offset_32-47 - Specifies the mask for packet bytes 32-47
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 32-35.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 36-39.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 40-43.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 44-47.
offset_48-63 - Specifies the mask for packet bytes 48-63.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 48-51.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 52-55.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 56-59.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 60-63.
offset_64-79 - Specifies the mask for packet bytes 64-79.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 64-67.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 68-71.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 72-75.
<hex 0x0-0xffffffff> - Enter the mask for packet bytes 76-79.
