xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
1232
DGS-3620-28SC:admin#config wred profile profile_id 2 min_threshold 30
max_threshold 50 max_drop_rate 10
Command: config wred profile profile_id 2 min_threshold 30 max_threshold 50
max_drop_rate 10
Success.
DGS-3620-28SC:admin#
116-5 config wred ports
Description
This command is used to configure the WRED parameters of the ports.
Format
config wred ports [<portlist> | all] [cos <class_id 0-7> [profile [default | profile_id <int 2-128>
| <profile_name 32>] | weight <int 0-15>] | profile [default | profile_id <int 2-128> |
<profile_name 32>] | weight <int 0-15>]
Parameters
<portlist> - Enter a range of ports to be configured.
all - Specifies all ports to be configured.
cos – Specify the hardware priority queues.
<class_id 0-7> - Enter the priority between 0 and 7.
profile - Specifies the profile to be used.
default - Specifies the default profile to be used.
profile_id - Specifies the profile ID to be used.
<int 2-128> - Enter the profile ID between 2 and 128.
<profile_name 32> - Enter the profile name to be used.
weight – Specify the weight of average queue size formular.
<int 0-15> - Enter the weight between 0 and 15.
profile - Specifies the profile to be used.
default - Specifies the default profile to be used.
profile_id - Specifies the profile ID to be used.
<int 2-128> - Enter the profile ID between 2 and 128.
<profile_name 32> - Enter the profile name to be used.
weight – Specify the weight of average queue size formular.
<int 0-15> - Enter the weight between 0 and 15.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the port 1:1 as queue 2 and to use the profile 2:
