xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
131
mask - Specifies the destination IP address used here.
<netmask> - Enter the destination network mask here.
dscp - (Optional) Specifies the value of DSCP. The DSCP value ranges from 0 to 63.
<value 0-63> - Enter the DSCP value used here. This value must be between 0 and 63.
icmp - (Optional) Specifies that the following parameters configured will apply to the ICMP
configuration.
type - Specifies that the rule will apply to the ICMP type traffic value.
<value 0-255> - Enter the ICMP traffic type value here. This value must be between 0
and 255.
code - Specifies that the rule will apply to the ICMP code traffic value.
<value 0-255> - Enter the ICMP code traffic value here. This value must be between 0
and 255.
igmp - (Optional) Specifies that the following parameters configured will apply to the IGMP
configuration.
type - Specifies that the rule will apply to the IGMP type traffic value.
<value 0-255> - Enter the IGMP type traffic value here. This value must be between 0
and 255.
tcp - (Optional) Specifies that the following parameters configured will apply to the TCP
configuration.
src_port - Specifies that the rule will apply to a range of TCP source ports.
<value 0-65535> - Enter the source port value here. This value must be between 0 and
65535.
mask - Specifies the TCP source port mask here.
<hex 0x0-0xffff> - Enter the TCP source port mask value here.
dst_port - Specifies that the rule will apply to a range of TCP destination ports.
<value 0-65535> - Enter the destination port value here. This value must be between 0
and 65535.
mask - Specifies the TCP destination port mask here.
<hex 0x0-0xffff> - Enter the TCP destination port mask value here.
flag - (Optional) Specifies the TCP flag fields.
all - Specifies that the TCP flag field will be set to 'all'.
urg - Specifies that the TCP flag field will be set to 'urg'.
ack - Specifies that the TCP flag field will be set to 'ack'.
psh - Specifies that the TCP flag field will be set to 'psh'.
rst - Specifies that the TCP flag field will be set to 'rst'.
syn - Specifies that the TCP flag field will be set to 'syn'.
fin - Specifies that the TCP flag field will be set to 'fin'.
udp - (Optional) Specifies that the following parameters configured will apply to the UDP
configuration.
src_port - Specifies the UDP source port range.
<value 0-65535> - Enter the UDP source port range value here.
mask - Specifies the UDP source port mask here.
<hex 0x0-0xffff> - Enter the UDP source port mask value here.
dst_port - Specifies the UDP destination port range.
<value 0-65535> - Enter the UDP destination port range value here.
mask - Specifies the UDP destination port mask here.
<hex 0x0-0xffff> - Enter the UDP destination port mask value here.
protocol_id - (Optional) Specifies that the rule will apply to the value of IP protocol ID traffic.
<value 0-255> - Enter the protocol ID used here. This value must be between 0 and 255.
user_define - (Optional) Specifies that the rule will apply to the IP protocol ID and that the
mask options behind the IP header, which has a length of 20 bytes.
<hex 0x0-0xffffffff> - Enter the user-defined mask value here.
mask - Specifies the user-defined mask here.
<hex 0x0-0xffffffff> - Enter the user-defined mask value here.
ipv6 - Specifies the rule applies to IPv6 fields.
class - (Optional) Specifies the value of IPv6 class.
<value 0-255> - Enter the IPv6 class value here. This value must be between 0 and 255.
source_ipv6 - (Optional) Specifies the value of IPv6 source address.
<ipv6addr> - Enter the source IPv6 source address here.
mask - Specifies the IPv6 source address mask here.
