xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
138
<value 1-4> - Enter the profile ID used here. This value must be between 1 and 4.
profile_name - Specifies the name of the profile.
<name 1-32> - Enter the profile name used here. This name can be up to 32 characters long.
access_id - Specifies the access ID.
<value 1-128> - Enter the access ID used here. This value must be between 1 and 128.
rate - This specifies the rate for single rate two-color mode. Specify the committed bandwidth in
Kbps for the flow. The value m and n are determined by the project.
<value 0-1048576> - Enter the rate for single rate two-color mode here. This value must be
burst_size - (Optional) This specifies the burst size for the single rate “two color” mode. The unit
is Kbytes.
<value 0-131072> - Enter the burst size value here. This value must be between 0 and
rate_exceed - This specifies the action for packets that exceed the committed rate in single rate
“two color” mode. The action can be specified as one of the following:
drop_packet - Drop the packet immediately.
remark_dscp - Mark the packet with a specified DSCP. The packet is set to have the higher
drop precedence.
<value 0-63> - Enter the remark DSCP value here. This value must be between 0 and 63.
tr_tcm - Specifies the “two rate three color mode”.
cir - Specifies the two rate three color mode used.
<value 0-1048576> - Enter the two rate three color mode value here. This value must be
between 0 and 1048576.
cbs - (Optional) Specifies the “Committed Burst Size”. The unit is Kbytes. That is to say, 1
means 1Kbytes. This parameter is an optional parameter. The default value is 4*1024.
<value 0-131072> - Enter the comitted burst size value here. This value must be between
0 and 131072.
pir - Specifies the “Peak Information Rate”. The unit is in Kbps. PIR should always be equal to
or greater than CIR.
<value 0-1048576> - Enter the peak information rate value here. This value must be
between 0 and 1048576.
pbs - (Optional) Specifies the “Peak Burst Size”. The unit is in Kbytes.
<value 0-131072> - Enter the peak burst size value here. This value must be between 0
and 131072.
color_blind - (Optional) Specify the meter mode to be color-blind. The default is color-blind
mode.
color_aware - (Optional) Specify the meter mode to be color-aware. When this code is
specified, user could set the “in-coming packet color” by using command “config
color_aware”. The final color of packet is determined by the initial color of packet and the
conform - (Optional) Specify the action when packet is in “green color”.
permit - Permit the packet.
replace_dscp - Changes the DSCP of the packet.
<value 0-63> - Enter the replace DSCP value here. This value must be between 0 and 63.
counter - (Optional) Specifies the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specifies that the ACL counter parameter will be enabled.
disable - Specifies that the ACL counter parameter will be disabled.
exceed - Specifies the action when packet is in “yellow color”.
permit - (Optional) Permit the packet.
replace_dscp - Changes the DSCP of the packet.
<value 0-63> - Enter the DSCP replace value here. This value must be between 0 and 63.
drop - Drops the packet.
counter - (Optional) Specifies the ACL counter. This is optional. The default is “disable”. The
resource may be limited so that a counter cannot be turned on. Counters will be cleared
when the function is disabled.
enable - Specifies that the ACL counter parameter will be enabled.
disable - Specifies that the ACL counter parameter will be disabled.
violate - Specifies the action when packet is in “red color”.
