xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
265
Example
To configure the LCK function state as enabled and specify a client level of 5:
DGS-3620-28SC:admin# config cfm lock md op-domain ma op-ma mepid 1 state enable
level 5
Command: config cfm lock md op-domain ma op-ma mepid 1 state enable level 5
Success.
16-30 config cfm trap
Description
This command is used to configure the state of the CFM trap.
Format
config cfm trap [ais | lock] state [enable | disable]
Parameters
ais - Specifies the AIS trap status to be configured. If the trap status of AIS is enabled, a trap will
be sent out when an ETH-AIS event occurs or clears.
lock - Specifies the LCK trap status that to be configured. If the trap status of LCK is enabled, a
trap will be sent out wnen an ETH-LCK event occurs or clears.
state – Specify the state of the CFM trap.
enable – Enable the CFM trap state. This is the default.
disable – Disable the CFM trap state.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command. (EI Mode Only
Command)
Example
DGS-3620-28SC:admin#config cfm trap ais state enable
Command: config cfm trap ais state enable
Success.
16-31 cfm dm
Description
This command is used to start a frame delay measurement test on an MEP. It will result in the
MEP periodically sending a DMM message to a remote MEP in the diagnostic interval. The system
will calculate the Frame Delay (FD) and Frame Delay Variation (FDV) based on the received DMR
