xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
687
advertisements.
dot3_tlvs - An individual port or group of ports to exclude one or more of IEEE 802.3
Organizationally Specific TLV data types from outbound LLDP advertisements.
all – (Optional) Configure all of the TLV optional data types below.
mac_phy_configuration_status - (Optional) This TLV optional data type indicates that LLDP
agent should transmit “MAC/PHY configuration/status TLV.” This type indicates it is
possible for two ends of an IEEE 802.3 link to be configured with different duplex and/or
speed settings and still establish some limited network connectivity. More precisely, the
information includes whether the port supports the auto-negotiation function, whether the
function is enabled, the auto-negotiated advertised capability, and the operational MAU
type. The default state is disabled.
link_aggregation - (Optional) This TLV optional data type indicates that LLDP agent should
transmit “Link Aggregation TLV.” This type indicates the current link aggregation status of
IEEE 802.3 MACs. More precisely, the information should include whether the port is
capable of doing link aggregation, whether the port is aggregated in an aggregated link,
and the aggregated port ID. The default state is disabled.
power_via_mdi - (Optional) This TLV optional data type indicates that LLDP agent should
transmit 'Power via MDI TLV'. The default state is disabled.
maximum_frame_size - (Optional) This TLV optional data type indicates that LLDP agent
should transmit “Maximum-frame-size TLV.” The default state is disabled.
enable - Enable the configuration of an individual port or group of ports to exclude one or
more of IEEE 802.3 Organizationally Specific TLV data types from outbound LLDP
advertisements.
disable - Disable the configuration of an individual port or group of ports to exclude one or
more of IEEE 802.3 Organizationally Specific TLV data types from outbound LLDP
advertisements.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To change the SNMP notification state of ports 1 to 5 to enable:
DGS-3620-28SC:admin#config lldp ports 1-5 notification enable
Command: config lldp ports 1-5 notification enable
Success.
DGS-3620-28SC:admin#
To configure the mode of ports 1 to 5 to transmit and receive:
DGS-3620-28SC:admin#config lldp ports 1-5 admin_status tx_and_rx
Command: config lldp ports 1-5 admin_status tx_and_rx
Success.
DGS-3620-28SC:admin#
To enable ports 1 to 5 to manage address entries:
DGS-3620-28SC:admin#config lldp ports 1-5 mgt_addr ipv4 192.168.254.10 enable
Command: config lldp ports 1-5 mgt_addr ipv4 192.168.254.10 enable
