xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
840
Example
To create OSPF area aggregation settings:
DGS-3620-28SC:admin# create ospf aggregation 10.1.1.1 192.168.0.0/16 lsdb_type
summary
Command: create ospf aggresgation 10.1.1.1 192.168.0.0/16 lsdb_type summary
Success.
DGS-3620-28SC:admin#
73-3 config ospf aggregation
Description
This command is used to configure the OSPF area aggregation settings.
Format
config ospf aggregation <area_id> <network_address> lsdb_type [summary {advertise
[enable | disable]} | nssa_ext {advertise [enable | disable]}]
Parameters
<area_id> - A 32-bit number in the form of an IP address (xxx.xxx.xxx.xxx) that uniquely
identifies the OSPF area in the OSPF domain.
<network_address> - The IP address that uniquely identifies the network that corresponds to
the OSPF Area. The network address format is 'IP address/prefix length'.
lsdb_type - Specifies the Link-State Database (LSDB) type of address aggregation.
summary - Specifies the LSDB type as summary.
advertise - (Optional) Allows for the advertisement of the summary LSDB.
enable - Specifies that the advertisement trigger will be enabled.
disable - Specifies that the advertisement trigger will be disabled.
nssa_ext - Specifies the LSDB type as a Not-So-Stub Area External Route (NSSA EXT).
advertise - (Optional) Allows for the advertisement of aggregated NSSA external route.
enable - Specifies that the advertisement trigger will be enabled.
disable - Specifies that the advertisement trigger will be disabled.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure the OSPF area aggregation settings:
DGS-3620-28SC:admin# config ospf aggregation 10.1.1.1 10.48.76.122/16 lsdb_type
summary advertise enabled
Command: config ospf aggregation 10.1.1.1 10.48.76.122/16 lsdb_type summary
advertise enabled
Success.
DGS-3620-28SC:admin#
