AV7000 LINEAR CAMERA REFERENCE MANUAL
Green = Online (connected and recognized in the cluster)
Gray = Unit not connected (unit not seen by master)
Yellow = Online, but not assigned to the cluster (shown under Cameras not in this
Cluster)
Red = Offline
Green = No errors and ready to read
Gray = Unit not connected (unit not seen by master)
Yellow = Warning present
Red = Error. If you click on the MAC address, it will take you to the status viewer
page for more info on the error
Displays the internal MAC Address (Media Access Control Address) the device
used for camera-to-camera communications.
Click the MAC Address link to view details about that specific device (See Device
Details below).
Displays the internal IP address of the unit used for camera-to-camera
communication.
Select Not Assigned, Top, Left, Right, or Bottom from the drop-down list.
Displays the camera's name assigned in Modify Settings | Device Settings |
<device> | Device Info.
Click Blink. This identifies the camera in the array. When clicked, the camera
illumination turns on for around 10 seconds.
Cameras not in
this Cluster
Displays a list of discovered cameras not currently included in the cluster. This
includes the same information listed above for each camera. See section 4.4 for
information on moving AV7000 cameras into the Cluster.
3. When you have finished making changes, click Update to save or click Reset to revert to
the previously saved values.
