AV7000 LINEAR CAMERA REFERENCE MANUAL
2.3 INSTALLATION SEQUENCE
NOTE: Everything should be MECHANICALLY INSTALLED before
performing any ELECTRICAL INSTALLATION.
See Chapter 3, Electrical Installation for electrical installation details.
To complete mechanical installation and setup, you must:
1. Review the details of your application’s requirements
2. Erect mounting structure or other supporting structures
3. Determine and mark the Mounting Bracket locations
4. Mount the brackets to the mounting structure
5. Mount the AI7000 Illuminator to its mounting brackets
6. Mount the fan assembly to the AV7000 Camera
7. Mount the AV7000 Camera to the Illuminator
8. Mount the brackets for the deflection mirror, if required.
9. Mount the deflection mirror to its brackets
10. Mount the height sensor (Light Curtain, RangeFinder, or DM3610 Dimensioner)
11. Mount the photoelectric sensor to the mounting structure (optional)
12. Mount the tachometer to the mounting structure
13. Mount the CBX connection box to the mounting structure
14. Complete electrical installation (See Chapter 3)
15. Align the AV7000 for proper operation
16. Align the height sensor for proper operation
17. Configure the AV7000 (See Chapter 4)
18. Calibrate the AV7000 (See Section 5.3)
19. Check AV7000 operations (See Section 5.4)
