5.8.2 AI7000 Illumination LEDs
The AI7000 Illumination has several LEDs on its back panel.
Figure 133: LED Indicators
The indicators have the following meanings:
Solid Red – Indicates internal temperature exceeding software or hardware
threshold
Solid Red – Indicates external cooling fan failure
Solid Red – Indicates one or more Illuminator LED boards has low current
or a failure
Solid Blue – Indicates illuminator Power ON
