AV7000 LINEAR CAMERA REFERENCE MANUAL
18
1
1.17 DM3610 DIMENSIONER
The DM3610 is used to detect the presence of products as they enter the scanning area as
well as report the package positions/heights and sequence number to all cameras in the
system. The DM3610 can also provide certified (Legal for Trade), side-by-side package
detection, or volume measurements for the packages that pass below it. See section 0 for
information on setting up the DM3610.
For complete information about the features and capabilities of the DM3610 Dimensioner,
see the dimensioner page on the Datalogic website: www.datalogic.com.
Figure 18: DM3610 Dimensioner
The DM3610 Dimensioner requires the following:
 DM3610
 Power Supply
 Universal Mounting Bracket
 Class 2 EU Adapter (optional)
