AV7000 LINEAR CAMERA REFERENCE MANUAL
6
1
1.6 MODEL DESCRIPTION
AV7000 cameras are available in versions that differ depending on the optical resolution
(focus range), while the AI7000 illuminators differ depending on the illuminated reading
width:
Figure 8: AV7000 Camera Model Description Key
Figure 9: AI7000 Illumination Model Description Key
1.7 AV7000 AND AI7000 VERSIONS
Model
Description
Part
Number
AV7000 BARCODE
READER
AV7000-1000
140mm f/5.6 STD
934001000
AV7000-1100
140mm f/5.6 SHORT RANGE
934001010
AV7000-1200
110mm f/8.0
934001020
AV7000-1300
90mm f/8
934001030
AI7000 ILLUMINATION
AI7000-800
SHORT RED LIGHTING SYS
934001100
AI7000-1100
MEDIUM RED LIGHTING SYS
934001110
AI7000-1500
LONG RED LIGHTING SYS
934001120
AI7000-800W
SHORT WHITE LIGHTING SYS
934001200
AI7000-1100W
MEDIUM WHITE LIGHTING SYS
934001210
AI7000-1500W
LONG WHITE LIGHTING SYS
934001220
AV7000 - 1 X 0 0
Optical Resolution:
0 = 140 mm Standard
1 = 140 mm Short
Range
2 = 110 mm
3 = 90 mm
AI7000 - X X 0 0
15 = Long
Reading Width:
8 = Short
11 = Medium
