Datalogic AV7000 Reference Manual

E-GENIUS
141
4
4.5.6 Modify Settings | Global Settings | Output Format
Use Output Format to format messages:
Output Format | Standard Formatter
Use the Standard Formatter to set up standard code parameters for output messages.
To edit the Standard Formatter settings:
1. In the menu tree under Modify Settings, navigate to Global Settings | Output Format |
Standard Formatter. The Standard Formatter window opens.
2. Enter the appropriate information in the form as described below:
Field Name
Action/Definition
Header
Click to activate the Text Entry Tool and create a header string. Headers (up to 128
bytes) can be defined and transmitted as a block preceding the barcode(s). Characters
from NUL (00H) to ~ (7EH) can be used.
Terminator
Click to activate the Text Entry Tool and create a terminator string. Terminators (up
to 128 bytes) can be defined and transmitted as a block following the barcode(s).
Characters from NUL (00H) to ~ (7EH) can be used.
Separator
Click to activate the Text Entry Tool and create a separator string. Separators (up
to 128 bytes) can be defined. Characters from NUL (00H) to ~ (7EH) can be used.
The Data Packet Separators (up to 128 bytes) are used to separate barcodes in the
reading phase. For this reason, it is very useful when the Multi Label parameter has
been enabled. If selected, they occur within the Code Field and are transmitted after
each decoded code.
