ELECTRICAL INSTALLA
TION
81
3
3.11.3
Encoder/Tachometer Wiring to CBX51
0
Encoder/Tachometer Wir
ing for NPN Output to CBX510
Figure
81
: OEK-2 Encoder/Tachometer Wiring (NPN Output)
NOTE:
Some Photocraft
tachometers may have a
different
color coding:
(+V)
Red
or
White/Orange
(Signal)
White
or
White/Bl
ue
(Ground)
Black
or
Orange
/White
92
94
