1.16 RANGEFINDER
The RangeFinder is used to detect the presence of products as they enter the scanning area
as well as report the package positions/heights and sequence number to all cameras in the
system. RangeFinders can also be used to provide rough dimensioning data. See section
5.2.2 for information on installing and calibrating the RangeFinder.
Figure 17: RangeFinder
The RangeFinder module includes the following:
 RangeFinder Module
 RangeFinder Power Supply
 Mounting and adjustment brackets
 Power Supply
RangeFinder
RANGEFINDER,DLA,0.1IN
93ACC0156
RANGEFINDER,DLA,0.2IN/5mm/10mm
93ACC0157
RANGEFINDER,DLA,0.5IN/20mm
93ACC0159
