MECHANICAL INSTALLATION

2 MECHANICAL INSTALLATION

2.1 PREPARING FOR MECHANICAL INSTALLATION

IMPORTANT: Application-specific drawings and documents

provided by Datalogic supersede any contradictory content in this

manual.

Before mounting any components, please do the following:

 Read all instructions before beginning your installation.

 Define and confirm the accuracy of your application’s requirements and structure position,

especially the height of the conveyor from the floor.

 Review all installation-specific drawings provided with your equipment.

 Review and plan the mechanical installation of all devices used in your application. Be

sure to allow adequate clearance for maintenance.

 Review and plan the power requirements for your application.

 Check the contents of the shipping cartons against the packing list.

 Record all product serial numbers.

NOTE: Refer to the Chapter 3 Electrical Installation and Reference

Documentation for details on connecting your readers to other devices

in the system.

WARNING: Electrical Installation must be performed by Qualified

Service Technicians Only! Procedures may involve exposure to

high-voltage. A trained and authorized technician must perform these

procedures. Do not attempt to perform any electrical installation

procedures unless you are a trained technician.

IMPORTANT: AV7000 cameras contain electronics that may be

affected by electrostatic discharge (ESD). To prevent personal injury

or damage to the unit, please follow the safety precautions and

warnings found in the References section at the beginning of this

manual. Failure to follow these precautions may void your warranty.

NOTE: When installing several AV7000s, take care to position them so

that no laser beam or LED illumination enters the reading window of other

barcode reading devices in the system. This condition could occur more

frequently for side mounted applications. If these precautions are not

followed, read rate could be negatively affected. To resolve this problem, it

is sufficient to slightly change the inclination and/or position of one of the

two devices involved.
