3.4 GENERAL ELECTRICAL INSTALLATION GUIDELINES AND
PRECAUTIONS
It is important that you follow these general precautions when installing, setting up, operating,
maintaining, troubleshooting or replacing any Datalogic products, parts or related equipment.
As you plan and install your barcode reader(s), be sure to keep the following guidelines in
mind:
 Determine the camera is in the proper location as outlined in Chapter 2.
 Leave adequate clearances (approximately 300mm [12 in]) for wiring.
 Route wires carefully to reduce or minimize electrical noise.
 When extraneous power and communication wiring must cross, make their intersection
perpendicular. Avoid running power and data wiring parallel to each other. If possible,
maintain one of the following separations between the power and data wiring:
 300 mm [12 in] gap
 use steel conduit and 25 mm [1 in] gap
 6.5 mm [0.25 in] of aluminum.
IMPORTANT: When planning your installation wiring, remember all
power connections must be quick-disconnect. For PERMANENTLY
CONNECTED EQUIPMENT a readily accessible disconnect device
must be incorporated in the building installation wiring. For
PLUGGABLE EQUIPMENT the socket-outlet must be installed near
the equipment and must be easily accessible
WARNING: To assure no ESD damage will occur, be sure to
observe the precautions outlined in the Introduction to this manual.
IMPORTANT: Ground the mounting structure to safety ground
(protective earth ground (PE)). See section 3.12 for wiring
recommendations for safety ground.
