AV7000 LINEAR CAMERA REFERENCE MANUAL
200
4
4.7.13 Diagnostics | Conveyor View
Use the Conveyor View window to view a representation of the packages currently on the
conveyor.
To access the Conveyor View window:
1. In the menu tree under Diagnostics, click Conveyor View. The Conveyor View window
opens.
2. Select the check box(es) by the option(s) you want to use.
 Stop After First Package
 Stop After Next Valid Read
 Stop After Next Multiple Read
 Stop After Next No Read
3. Select Left to Right or Right to Left from the Conveyor Direction drop-down list to shift
the orientation.
4. Select the Use STD (standard) Analysis or Use Custom Analysis option button. If the
Use Custom Analysis option is selected, you can then select a numbered Transport
from the drop-down list that appears.
5. Click Start to view a representation of packages moving along the conveyor, or click
Stop to freeze the window.
NOTE: Hold the cursor of the package shown on
the conveyor animation to view package
information, including Event, Tach Count, and
Package Number information.
