MECHANICAL INSTALLA
TION
23
2
2.4
INSTALLATION
2.4.1
Dimensions and Clearances
Figure
21
: Mounting Dimensions
IMPORTANT:
The
AV7000
is
a
se
aled,
unventilated
unit.
Mounting
the
unit
with
300
mm
[12
in]
of
clearance
(front,
top,
and
sides)
is
recommended
for
cooling
and
ease
of
maintenance.
Note:
The
AV7000
datum
is
indicated
by
the
das
hed
line.
As
indicated,
the
range
to
the
target
is
measured
from
the
camera/illumination interface plane.
