Datalogic AV7000 Reference Manual

INTRODUCTION
13
1
1.12 ENCODER (TACHOMETER)
The encoder/tachometer delivers a continuous pulse to the system, which provides feedback
on conveyor speed and transmit point, and can be used to help track the package position
along the length of the conveyor. See section 3.10.3 and 3.11.3 for wiring options.
Figure 13: Encoder/Tachometer, Mounting Bracket, and Cable
Encoder (Tachometer)
OEK-2 OPTICAL ENCODER (CAB 10m+SPRING)
93ACC1770
OEK-3 OPTICAL ENCODER HI RES,6M CBL+SPRI
93ACC0056
OEK-3 ENCODER HI RES M139,6M CBL +SPRI (START/STOP ANTI
ROLLBACK)
93ACC0104
