AV7000 LINEAR CAMERA REFERENCE MANUAL
206
4
4.8.1 Advanced Cluster Configuration
Use Advanced Cluster Configuration to reorganize the cameras in a Tunnel/Array.
WARNING: DO NOT use Advanced Cluster
Configuration unless authorized by Datalogic
Support. Using this function without Datalogic
Support can harm system operation.
To access the Advanced Cluster Configuration window:
1. In the menu tree under Utilities, click Advanced Cluster Configuration. The Advanced
Cluster Configuration window opens.
The enabled columns (not greyed out) show the AV7000 cameras currently online in the
system. If a camera is not online (greyed out) you can still select it for action.
To Swap Two Cameras in the same tunnel:
2. Select the check boxes in the Select for Action column corresponding to the cameras
you want to swap.
3. Click Swap Cameras. The selected cameras swap MAC addresses.
