Datalogic AV7000 Reference Manual

TECHNICAL FEATURES
313
8
8 TECHNICAL FEATURES
This chapter provides detailed specifications for the AV7000 Barcode Reading Systems. It
provides specific information on:
 Electrical Features
 Optical Features
 Reading Features
 Human Machine Interface
 Software Features
 Environtmental Features
 Physical Features
8.1 TECHNICAL SPECIFICATIONS
ELECTRICAL FEATURES
Supply Voltage
23-26VDC at illumination connector
24 VDC ± 2% at power supply connector
Power Consumption
AV7000
Camera
4A
Illumination Color:
Red
White
AV7000 Camera + AI7000-800 Illumination
12A
15.3A
AV7000 Camera + AI7000-1100 Illumination
16.5A
20A
AV7000 Camera + AI7000-1500 Illumination
20A
22A
Electrical Protection
Internal Electronic Polarity Inversion Protection for
both AV7000 cameras and AV7000 illuminators
Common
Communication
Interfaces
Main
Baud Rate
RS232/RS422
up to 115.2
Kbit/s
1200 to 115200
Auxiliary
RS232 up to
115.2 Kbit/s
1200 to 115200
Ethernet
2 x Ethernet TCP/IP
 1 Ethernet Gigabit for decoding data to Host
(may also be used for setup)
 1 Ethernet Gigabit for image file transfer to
Host
Digital Inputs
3 x Inputs (2 + 1 x “Encoder”), optocoupled, NPN/PNP (5-30 Vdc)
 1 Presence Sensor opto-isolated (polarity insensitive)
 1 Optical Encoder opto-isolated (polarity insensitive)
 1 General Purpose opto-isolated (polarity insensitive)
