Datalogic AV7000 Reference Manual

IMAGING FEATURES
269
5
#
LED
Description
NET
Green – Image Network Link at Gbit speed
Red – Image Network Data activity
NOTE: With a Gbit link, Green will always be
on and Red will blink, looking like it alternates
Green to amber. If connected to 100Mbit
network, the LED will only blink Red with
activity.
SYNC IN
Green – SyncNet Link at 100Mbit speed
Red – SyncNet Data activity
NOTE: With a 100Mbit link, Green will always
be on and Red will blink, looking like it
alternates Green to amber. If connected to
100Mbit network, the LED will only blink Red
with activity.
SYNC OUT
Green – SyncNet Link at 100Mbit speed
Red – SyncNet Data activity
NOTE: With a 100Mbit link, Green will always
be on and Red will blink, looking like it
alternates Green to amber. If connected to
100Mbit network, the LED will only blink Red
with activity.
FOCUS
NET
Green – Focus Network Link at 100Mbit speed
Red – Focus Network Data activity
NOTE: With a 100Mbit link, Green will always
be on and Red will blink, looking like it
alternates Green to amber. If connected to
100Mbit network, the LED will only blink Red
with activity.
7
8
9
10
