Datalogic AV7000 Reference Manual

E-GENIUS
127
4
Modify Settings | Global Settings | Barcode Settings | Advanced Decode
Use Advanced Decode to set up and enable advanced code settings.
To edit the Advanced Decode Settings:
1. In the menu tree under Modify Settings, navigate to Global Settings | Advanced
Decode. The Advanced Decode window opens.
2. Enter the appropriate information in the form as described below:
Field Name
Action/Definition
Enable Low
Profile 1D
Codes
Select the check box to enable reading of low profile 1D barcodes.
Enable Low
Contrast
Improvements
Select the check box to enable automatic contrast improvements.
Code and
Background
Color
Select Black on White, White on Black, or Both from the drop-down list to match
the kind of barcodes read by the system.
Advanced Localizer Settings
Enable
Advanced
Localizer
Select the check box to enable the advanced localizer options. DO NOT change this
parameter unless directed by Datalogic Support.
ROI Usage
(Region of
Interest)
Select a code profile from the drop-down list to match the type of barcodes read by
the system. Do not change this parameter unless directed by Datalogic
Support.
ROI Threshold
The ROI Threshold factor in the field provided. To improve decode time, this allows
for the restriction of the decoding region of interest. The default value is 60. Do not
change this parameter unless directed by Datalogic Support.
3. When you have finished making changes, click Update to save or click Reset to revert to
the previously saved values.
