Field Name
Definition
Mounting
Calibration
Wizard
Click to open the Mounting Calibration Wizard (see section 4.6.3).
This is used during initial static calibration only.
View Angle
Enter an angle (degrees) in the field provided.
This parameter allows defining the reading angle of the camera. For standard
installations this angle should be set to match the mechanical mounting: +15 or -15
degrees (single side object reading), +45-degrees for a side/back read or -45-
degrees for a side/front read (double side object reading) depending on the type of
installation. This parameter may be up to two degrees different then the 15/45
degree after the completed calibration.
For top read single side, +15-degrees is facing downstream, and -15-degrees is
facing upstream. For top read multi-side, +45-degrees for top/back and -45-degrees
for top/front.
Positive angles correspond to the package front or leading side with respect to the
package movement and negative angles correspond to the package back or trailing
side.
This field is automatically filled in during the static calibration of the unit (Calibration
Wizard), but may be changed during dynamic calibration.
The possible values are from -50° to +50°. The default setting is 15°.
Distance to
Trigger Source
(X)
Defines the distance from the camera scan line to the trigger source (typically a
RangeFinder or DM3610 Dimensioner).
This field is automatically filled in during the static calibration of the unit (Calibration
Wizard), but may be changed during dynamic calibration.
Far Working
Distance (Z)
Defines the distance from the camera to the furthest scanning point.
This field is automatically filled in during the static calibration of the unit (Calibration
Wizard), but may be changed during dynamic calibration.
Global Gain
with
Continuous
Illumination
Enter the gain value. A typical value would be 1.0.
This parameter sets the gain in the image to create the contrast between the dark
and light elements in the image.
This field is automatically filled in during the static calibration of the unit (Calibration
Wizard), but may be changed during dynamic calibration.
Global Gain
with Pulsed
Illumination
Enter the gain value. This parameter is only used when Pulsed Illumination
Enable is selected in Modify Settings | Device settings | Camera x | Imaging.
This parameter sets the gain in the image to create the contrast between the dark
and light elements in the image.
This field is automatically filled in during the static calibration of the unit (Calibration
Wizard), but may be changed during dynamic calibration.
3. When you have finished making changes, click Update to save or click Reset to revert to
the previously saved values.
