Datalogic AV7000 Reference Manual

E-GENIUS
179
4
Field Name
Action/Definition
Auto DNS
Enable
Select the check box to automatically assign a DNS address. When not selected,
the DNS Address field is revealed. Available only in static IP mode (when DHCP is
not selected).
DNS Address
Enter the address of the Secondary Domain Name System (DNS) in the field
provided.
3. When you have finished making changes, click Update to save or click Reset to revert to
the previously saved values.
0.
Ethernet | Image Port
Use the Image Port window to set up network communications from the Image Port to a
server.
To edit the Image Port settings:
1. In the menu tree under Modify Settings, navigate to Modify Settings | Device Settings |
Camera N | Ethernet | Image Port. The Image Port window opens.
2. Enter the appropriate information in the form as described below:
Field Name
Action/Definition
Enable DHCP
Select the check box to use addresses assigned by a DHCP server. When not
selected, the static IP options are made available.
IP Address
Enter the device Internet Protocol (IP) network address in the field provided.
Consult your network administrator to obtain a new address. Available only in static
IP mode (when DHCP is not selected).
Subnet Mask
Enter the device subnet mask address in the field provided. Consult your network
administrator to obtain a new address. Available only in static IP mode (when
DHCP is not selected).
Gateway
Enter the device gateway address in the field provided. Consult your network
administrator to obtain a new address. Available only in static IP mode (when
DHCP is not selected).
Auto DNS
Enable
Select the check box to automatically assign a DNS address. When not selected,
the DNS Address field is revealed. Available only in static IP mode (when DHCP is
not selected).
DNS Address
Enter the address of the Secondary Domain Name System (DNS) in the field
provided.
