Delta DVP-15MC Series User Manual

Chapter 8 Logic Instructions
8-21
8_
FB/FC
Explanation
Applicable model
FC
MoveBit is used for sending one bit in a string.
DVP15MC11T
DVP15MC11T-06
 Parameters
Parameter
name
Meaning
Input/
Output
Description Valid range
In
Input
signal
Input Move source
Depends on the data type of the variable
that the input parameter is connected to.
InPos
Input
signal
Input Move source bit
Depends on the data type of the variable
that the input parameter is connected to.
InOutPos
Input
signal
Input Move destination bit
Depends on the data type of the variable
that the input parameter is connected to.
InOut
Input
signal
Input Move destination
Depends on the data type of the variable
that the input parameter is connected to.
Boolean
Bit string Integer
Real
number
Time, date
String
BOOL
BYTE
WORD
DWORD
LWORD
USINT
UINT
UDINT
ULINT
SINT
INT
DINT
LINT
REAL
LREAL
TIME
DATE
TOD
DT
STRING
In
● ● ● ● ● ● ● ●
InPos
●
InOutPos
●
InOut
● ● ● ● ● ● ● ●
Note:
The symbol ● indicates that the parameter is allowed to connect to the variable or constant of the data
type.
 Function Explanation
MoveBit moves one bit value from the bit position InPos in move source In to the bit position InOutPos
in move destination InOut.
 Precautions for Correct Use
 The instruction has no ouput but input.
1
MOVE
EN ENO
In Out
MOVE_EN
MOVE_In Out1
MoveBit
EN ENO
In
InPos
InOutPos
InOut
