Delta DVP-15MC Series User Manual

Chapter 8 Logic Instructions
8-167
8_
Data type
The value of In corresponds to the value of Out
In
Out
In
Out
WORD
16#****_0000~16#****_FFFF
16#0000~16#FFFF
DWORD
16#0000_0000~16#FFFF_FFFF
16#0000_0000~16#FFFF_FFFF
LWORD
16#0000_0000~16#FFFF_FFFF
16#0000_0000_0000_0000~
16#0000_0000_FFFF_FFFF
ULINT
BYTE
16#****_****_****_**00~
16#****_****_****_**FF
16#00~16#FF
WORD
16#****_****_****_0000~
16#****_****_****_FFFF
16#0000~16#FFFF
DWORD
16#****_****_0000_0000~
16#****_****_FFFF_FFFF
16#0000_0000~16#FFFF_FFFF
LWORD
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
SINT
BYTE
16#00~16#FF
16#00~16#FF
WORD
16#00~16#FF
16#0000~16#00FF
DWORD
16#00~16#FF
16#0000_0000~16#0000_00FF
LWORD
16#00~16#FF
16#0000_0000_0000_0000~
16#0000_0000_0000_00FF
INT
BYTE
16#**00~16#**FF
16#00~16#FF
WORD
16#0000~16#FFFF
16#0000~16#FFFF
DWORD
16#0000~16#FFFF
16#0000_0000~16#0000_FFFF
LWORD
16#0000~16#FFFF
16#0000_0000_0000_0000~
16#0000_0000_0000_FFFF
DINT
BYTE
16#****_**00~16#****_**FF
16#00~16#FF
WORD
16#****_0000~16#****_FFFF
16#0000~16#FFFF
DWORD
16#0000_0000~16#FFFF_FFFF
16#0000_0000~16#FFFF_FFFF
LWORD
16#0000_0000~16#FFFF_FFFF
16#0000_0000_0000_0000~
16#0000_0000_FFFF_FFFF
LINT
BYTE
16#****_****_****_**00~
16#****_****_****_**FF
16#00~16#FF
WORD
16#****_****_****_0000~
16#****_****_****_FFFF
16#0000~16#FFFF
DWORD
16#****_****_0000_0000~
16#****_****_FFFF_FFFF
16#0000_0000~16#FFFF_FFFF
LWORD
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
16#0000_0000_0000_0000~
16#FFFF_FFFF_FFFF_FFFF
 Integer to Integer
 The Integer data can be converted to the Integer data. And some instructions are shown
below.
1. The rule for the conversion of the Integer data into the Integer data is the same as that for
the conversion of the Bit-string data into the Bit-string data.
SINT_TO_INT
EN ENO
Out
In
INT_TO_SINT
EN ENO
Out
In
USINT_TO_DINT
EN ENO
Out
In
UINT_TO_ULINT
EN ENO
Out
In
