Delta DVP-15MC Series User Manual

DVP-15MC Series Motion Controller Operation Manual
8-166
_8
 The Integer data are converted into the Boolean data as the following table shows. If the
Integer value is 0, the conversion result is FALSE. If not 0, the result is TRUE. For details on
the conversion rule, see the table as follows.
Data type
The value of In corresponds to the value of Out
In
Out
In
Out
USINT BOOL
0
FALSE
1~255
TRUE
UINT BOOL
0
FALSE
1~65535
TRUE
UDINT BOOL
0
FALSE
1~4294967295
TRUE
ULINT BOOL
0
FALSE
1~18446744073709551645
TRUE
SINT BOOL
0
FALSE
-128~-1, 1~127
TRUE
INT BOOL
0
FALSE
-32768~-1, 1~32767
TRUE
DINT BOOL
0
FALSE
-2147483648~-1, 1~2147483647
TRUE
LINT BOOL
0
FALSE
-9223372036854775808~-1,
1~9223372036854775807
TRUE
 Integer to Bit string
 The Integer data can be converted to the Bit-string data. And some instructions are shown
below.
The rule for the conversion of the Integer data into the Bit-string data is the same as that for
the conversion of the Bit-string data into the Bit-string data. Refer to section 8.13.2 for details.
 The Integer data are converted into the Bit-string data as the following table shows.
Data type
The value of In corresponds to the value of Out
In
Out
In
Out
USINT
BYTE
16#00~16#FF
16#00~16#FF
WORD
16#00~16#FF
16#0000~16#00FF
DWORD
16#00~16#FF
16#0000_0000~16#0000_00FF
LWORD
16#00~16#FF
16#0000_0000_0000_0000~
16#0000_0000_0000_00FF
UINT
BYTE
16#**00~16#**FF
16#00~16#FF
WORD
16#0000~16#FFFF
16#0000~16#FFFF
DWORD
16#0000~16#FFFF
16#0000_0000~16#0000_FFFF
LWORD
16#0000~16#FFFF
16#0000_0000_0000_0000~
16#0000_0000_0000_FFFF
UDINT
BYTE
16#****_**00~16#****_**FF
16#00~16#FF
SINT_TO_BYTE
EN ENO
OutIn
INT_TO_WORD
EN ENO
OutIn
USINT_TO_DWORD
EN ENO
Out
In
UINT_TO_LWORD
EN ENO
Out
In
